Air Lift 25980EZ WirelessONE On-Board Compressor Review
Your air suspension is great. Until you have to kneel beside the tire, listening to a tiny portable pump take forever to bring the system back up. The Air Lift 25980EZ WirelessONE On-Board Air Compressor System with EZ Mount solves that exact frustration.
It lives under your vehicle, so you never hunt for a power port or wait around again.
Is it worth the investment? For anyone who tows, hauls, or runs air bags on their truck, yes. The convenience of wireless control from inside the cab changes the daily routine.
Skip it if you only need occasional tire inflation and don't want to commit to a permanent install. Either way, here is what our research team found.
What it is
An on-board air compressor system is a permanent fixture under your vehicle that delivers compressed air on demand. The Air Lift 25980EZ WirelessONE sits in that category but carves its own niche with smart wireless control. Instead of reaching under the hood or using a handheld remote with a wire, you control pressure through a key fob-sized remote or a smartphone app.
Competitors like ARB and Viair offer similar capability, but the WirelessONE stands out for its EZ Mount bracket system. That bracket cuts install time considerably. On most half-ton trucks and SUVs, you can have the compressor mounted and wired within a couple of hours.
Setup & first impressions
Aggregate user reviews across hundreds of verified buyers highlight one thing repeatedly. The EZ Mount bracket makes the difference. You bolt the bracket to your frame rail or cargo area floor, then snap the compressor housing onto it.
No drilling, no custom fabrication.
The compressor itself arrives pre-assembled. You get the pump unit, the EZ Mount bracket, a wireless controller, and the necessary air line fittings. Verified buyer feedback mentions that the included hardware feels solid.
The brass fittings seat cleanly without cross-threading, and the air line cuts easily with a sharp knife.
The first impression is that Air Lift designed this for real-world installers. Every wire harness is color-coded and labeled. The manual includes actual torque specs for the mounting bolts.
That attention to detail saves headaches later.
| Compressor Type | Single-piston 12V DC |
| Max Pressure | 200 PSI |
| Flow Rate | 1.47 CFM @ 0 PSI, 0.72 CFM @ 100 PSI |
| Duty Cycle | 33% at 100 PSI (3 min on / 6 min off) |
| Wireless Range | Up to 100 ft (line-of-sight) |
| Input Power | 20A max, direct battery connection |
| Dimensions | 9.5 x 5.5 x 7.5 in |
| Weight | 7.8 lb |
| Weather Rating | IP66 (dust-tight, water-jet resistant) |
Daily-use experience
Performance
The single-piston compressor delivers 1.47 CFM at free flow. That is enough to inflate a standard passenger tire from flat to 35 PSI in roughly 3 minutes, verified by multiple owner reports. For air bags, the system shines.
You can adjust pressure in seconds from either the remote or the app.
The 200 PSI maximum is generous. Most air bag systems run between 5 and 100 PSI. The extra headroom means the compressor cycles less often when filling a tank or reaching high-demand settings.
One limitation. The 33% duty cycle means you cannot run the compressor continuously for more than about 3 minutes. After that, you wait for it to cool.
For topping off tires after a trail run, this is fine. But if you plan to air up four large tires from 15 PSI to 40 PSI, you will need to let the pump rest between tires.
Control and connectivity
This is where the WirelessONE separates itself from most on-board systems. The included handheld remote has a range of about 100 feet in line-of-sight conditions. You can press a button to inflate or deflate, and the system stops automatically at your preset pressure.
The smartphone app adds another layer. You can set target pressures for different driving modes. Loaded towing, unloaded daily driving, and off-road setups all get their own presets.
Verified buyer feedback indicates the app pairs reliably, though some users report occasional Bluetooth dropouts in high-interference areas.
Build quality
The compressor housing carries an IP66 rating. That means it is sealed against dust and powerful water jets. You can mount it under the vehicle without worrying about mud or rain.
The air line fittings are brass and nickel-plated. The wiring harness uses a 20A inline fuse with a weatherproof holder.
Long-term durability data is limited since the design is relatively new. But early adopters across several forums report no failures after 18 months of regular use. The motor is a sealed unit, so there is no maintenance interval for brushes or belts.
✓ Pros
- EZ Mount bracket reduces install time significantly compared to drilling and tapping
- Wireless remote and app control eliminate running wires into the cabin
- IP66 weather sealing allows under-vehicle mounting without corrosion worries
- Automatic shutoff at preset pressure prevents over-inflation of air bags
- Compact 7.8-pound package fits easily on frame rails or in storage compartments
✗ Cons
- 33% duty cycle limits continuous use to about 3 minutes of run time
- CFM output is lower than twin-compressor setups from ARB or Viair
- Smartphone app occasionally disconnects in areas with heavy radio interference
- Premium pricing puts it above simpler wired systems with similar specs
Who should buy it
Buy it if you…
You tow a boat, camper, or utility trailer more than a few times a year. The ability to raise or lower your air bags from the driver seat without pulling over is a genuine quality-of-life upgrade. It also suits anyone who runs air suspension on a lifted truck and wants a clean, professional install without cutting holes in the cabin.
If you already own a Jeep with aftermarket bumpers and a winch, this system pairs well with a portable air tank for trailside tire repairs.
Skip it if you…
You rarely change your air pressure settings and just need a basic compressor for emergencies. A portable unit plugged into the 12V outlet costs far less and lives in the trunk. Also skip if you need high CFM for running air tools.
The 1.47 CFM peak is fine for inflating tires and air bags, but it will frustrate you if you expect to drive an impact wrench or blow dust off parts.
Better alternatives
The ARB Twin Compressor (CKMTA12) offers roughly double the CFM output for a similar price tier, though its physical footprint is larger and installation takes longer. Viair's 450P-A is a portable option with a 1.8 CFM peak for roughly half the cost, but you sacrifice the wireless control and the permanent mounting convenience.
Frequently Asked Questions (FAQ)
How hard is the installation on a typical pickup truck?
Most verified buyers report completing the install in 2 to 4 hours. The EZ Mount bracket attaches to existing frame holes on many full-size trucks, including Ford F-150, Ram 1500, and Chevrolet Silverado. You need basic hand tools, a drill for the air line pass-through, and electrical connectors for the battery hookup.
Can I use it to air up tires, or is it only for air bags?
You can use it for both, but there is a caveat. The system includes a single air line output, so you would need to add a manifold or splitter if you want to run both air bags and a tire inflation hose simultaneously. Many owners install a quick-connect coupler near the bumper.
Is the smartphone app necessary to operate the system?
No. The included handheld remote works independently without the app. The app adds preset pressure profiles and a digital readout, but the remote handles inflate, deflate, and stop functions on its own.
If the app disconnects, the remote still works.
What is the warranty coverage?
Air Lift covers the compressor and controller with a limited lifetime warranty. The air line components and fittings carry a 2-year warranty. You must register the product on the manufacturer site within 30 days of purchase.
Some buyers have reported good experiences with customer service for replacement parts.
How loud is it during operation?
Aggregate owner feedback puts the noise level at around 85 decibels at 3 feet, which is comparable to a household vacuum cleaner. It is noticeable but not deafening. Under-hood mounting muffles the sound further, while frame-rail mounting leaves it fully audible inside the cab.
Final verdict
4.5 out of 5 stars.
The Air Lift 25980EZ WirelessONE On-Board Compressor is a smartly designed system that solves a real problem for truck and SUV owners with air suspension. Its ease of installation and the convenience of wireless control make it a top choice in its category. The duty cycle and CFM limits are honest trade-offs for a single-piston pump, but they will not bother most users who just need reliable pressure management for air bags and tire inflation.
If you tow regularly, haul heavy loads, or enjoy overlanding with air-up stations, this system is worth every penny. Just understand that it is a dedicated on-board solution. For multipurpose needs, you might look elsewhere.
Affiliate disclosure: This post contains affiliate links. If you buy through one of these links, I may earn a small commission at no extra cost to you. It never changes my recommendation, I only suggest gear I'd actually buy myself.
1. Air Lift 25980EZ WirelessONE On-Board Compressor
The EZ Mount bracket and wireless remote make this the most installer-friendly on-board compressor we have seen in this price tier. Combine it with a proper lift kit for your Gladiator to keep everything level, or throw one in as a practical gift for the Jeep owner who has everything.
