Your Ao Smith tankless water heater troubleshooting session starts the same way for most homeowners: a cold shower and a flashing error code. That tiny digital display is trying to tell you exactly what's wrong, but the manual is buried somewhere, and the code lookup table feels like a puzzle. Let's change that.
As of 2026, AO Smith's residential tankless lineup covers models with flow rates from 3.5 to 8.0 GPM and BTU inputs up to 199,000. The error code system is standardized across most of them, so once you know how to read the display, you can skip the guesswork and start fixing. Here's how to walk through the problem without making it worse.
Quick Answer
The most common Ao Smith tankless problems fall into three categories: no ignition, temperature issues, or leaks. Each one maps to a specific error code. Start by writing down the code on the display.
Then follow the branch below for that code. If the unit has no code at all, check power, gas, and water flow first.
Image source: Bing (Web (fair-use with source credit))
The Three Core Branches (by Symptom)
Your troubleshooting path depends entirely on what the unit is doing (or not doing). Every symptom links to a handful of common causes. We've broken them into three branches so you can jump straight to the one that fits your situation.
Branch A: No Heat / No Ignition (Error Codes E01, E02, E09)
What to do if you see E01, E02, or E09. These codes mean the unit is trying to light the burner but failing. Start with the simplest checks first. Make sure the gas supply valve is fully open.
Then listen for the fan spinning when you turn on a hot water tap. If the fan is silent, check the blower motor for blockage or a bad capacitor. If the fan runs but you hear no spark, clean the igniter with fine sandpaper.
A dirty flame sensor (the metal rod near the burner) can also cause flame failure. Wipe it gently with a Scotch-Brite pad. If the unit still won't light, measure the gas pressure at the inlet with a manometer.
Per AO Smith's service bulletins, natural gas units need 5 to 10.5 inches of water column static pressure. Propane units require 11 to 13 inches. Low gas pressure is a common hidden culprit.
Image source: Bing (Web (fair-use with source credit))
Branch B: Water Temperature Problems (Error Codes E03, E06, Fluctuating Temp)
What to do if the water is too hot, too cold, or swinging wildly. Error E03 means overheating, which almost always points to scale buildup inside the heat exchanger. Hard water minerals reduce flow and trap heat. The fix is a descaling flush using a pump kit and a vinegar-or-citric-acid solution.
For fluctuating temperature, check the inlet water filter (Y-strainer) first. A partially clogged strainer reduces flow and tricks the unit into cycling on and off. Also verify that the flow rate is above the unit's minimum activation point, usually 0.5 GPM.
If you're using a low-flow showerhead, that could be the problem. Another overlooked cause is the gas pressure modulating incorrectly. If the manifold pressure drifts outside the 3.5 to 5.5 inches WC range for natural gas, the burner can't hold a steady flame.
Branch C: Leaks, Freeze Damage, or Flow Issues (Error Codes E05, E07, E08, E10)
What to do if water is dripping, the unit is frozen, or you get a blower error. Error E05 means the blower motor is locked or malfunctioning. Check for obstructions in the vent pipe, such as bird nests, ice, or soot buildup. Also inspect the motor itself for seized bearings.
Error E07 is the freeze protection alarm. If the outdoor temperature drops below 32°F and the unit loses power, the internal heater pads can't activate. Drain the unit immediately to prevent heat exchanger cracks.
Error E08 indicates abnormal current leakage, often from a wet control board. Error E10 is a communication error between the control board and the display board. This usually requires a board replacement.
For any water leak, check the condensate drain line first. A clogged line backs up and drips from the unit's bottom seam.
Image source: Web (Bing) / smartwatersource.com (Web image (fair-use with source credit))
Mistakes to Avoid During Troubleshooting
The first mistake people make is skipping the power cycle. Before you take anything apart, turn off the unit's power for 30 seconds, then turn it back on. A simple reset clears many temporary errors.
The second mistake is ignoring the gas supply. Always confirm the valve is open before digging into the burner assembly. The third mistake is using the wrong tools.
A multimeter is essential for testing thermistors and the flame sensor. A manometer is required for gas pressure checks. Using guesswork instead of measurement leads to wasted time and repeated callbacks.
The fourth mistake is forgetting to shut off the gas before removing any components. A small leak can turn into a big problem fast. Finally, never run the unit without the front cover properly secured.
The pressure switch and flame sensor rely on proper airflow inside the cabinet.
Maintenance Tips That Prevent Most Callouts
Tankless water heaters are low-maintenance but not no-maintenance. The single most important task is annual descaling. Hard water deposits build up inside the heat exchanger over time, reducing efficiency and eventually triggering error E03.
A simple flush kit costs around $40 and takes about an hour. Use white vinegar or a citric acid solution specifically rated for tankless units. The second task is cleaning the inlet water filter.
This Y-shaped brass screen catches sediment from the incoming supply. A clogged filter reduces flow and causes intermittent hot water. Check it every six months, especially if your home uses well water.
The third task is inspecting the vent piping. Look for bird nests, dirt dauber mud, or ice buildup at the termination cap. Blocked venting can cause flame rollout or carbon monoxide leakage.
| Maintenance Task | Frequency | Tools Needed |
|---|---|---|
| Descaling flush | Annually (every 6 months in hard water areas) | Flush pump, vinegar or citric acid, bucket, hoses |
| Clean inlet filter | Every 6 months | Adjustable wrench, bucket for catch water |
| Inspect vent termination | Before winter and after storms | Flashlight, ladder if outdoors |
| Check gas pressure | Annually or after any gas line work | Manometer, gas valve wrench |
| Test freeze protection | Before first freeze | Visual check of heater pads, drain test |
Safety Reminders (Gas, Electrical, Freeze)
Working on a gas appliance involves real risks. Carbon monoxide poisoning is the most serious. If you smell gas near the unit, shut off the gas immediately and open windows.
Do not operate any electrical switches or create sparks. Call your gas utility or a licensed technician from outside the building. For electrical safety, always disconnect power at the breaker box before opening the unit's cabinet.
The control board stores voltage in capacitors even after the power is off. Wait two minutes after disconnecting before touching any components. Freeze protection is another critical safety concern.
If the power goes out during freezing weather, the unit's internal heater pads stop working. Drain the unit by closing the gas valve, shutting off the water supply, and opening the hot water tap. Remove the drain plug at the bottom of the unit to let all water exit the heat exchanger.
Per the National Fuel Gas Code (NFPA 54) and AO Smith's installation manuals, a frozen heat exchanger can crack and require full replacement.
Frequently Asked Questions
What does error code E01 mean on my Ao Smith tankless water heater?
Error E01 means ignition failure. The unit tried to light the burner but couldn't. Start by checking the gas supply valve and listening for the fan spinning.
If the fan runs but there is no spark, clean the igniter and flame sensor with fine sandpaper.
How do I reset my Ao Smith tankless water heater?
Turn off the power at the breaker or disconnect switch. Wait 30 seconds. Turn the power back on.
This clears most temporary error codes. If the code returns immediately, there is a real problem that needs further diagnosis.
Why does my Ao Smith tankless water heater keep shutting off?
The most common cause is a dirty inlet filter or a clogged heat exchanger from mineral scale. Low gas pressure or a loose flame sensor connection can also cause the burner to cycle on and off. Check the error code on the display for a more specific clue.
How often should I descale my Ao Smith tankless water heater?
Descaling should happen at least once per year. If you live in an area with hard water above 7 grains per gallon, increase that to every six months. A descaling flush takes about an hour with a pump kit and cleaning solution.
Can I install an Ao Smith tankless water heater myself?
Manufacturer instructions and local building codes typically require a licensed professional for gas and venting connections. DIY installation of the water lines and mounting is possible, but gas line work and vent sizing should be done by a qualified technician. Improper installation voids the warranty.
What causes error code E07 on my Ao Smith tankless?
Error E07 is the freeze protection alarm. It triggers when internal sensors detect freezing conditions and the heater pads cannot keep the unit warm enough. This usually happens during a power outage in cold weather.
Drain the unit immediately to prevent a cracked heat exchanger.
