jiaji 12V 13700 BTU Under Dash Review
You’re driving through the desert in July, windows down, sweat soaking through your shirt. The AC in your van or truck just can’t keep up, or maybe you don’t have one at all. That’s the exact moment you start searching for a jiaji 12V 13700 BTU Under Dash Air Conditioner, a compact, 12-volt electric unit built to cool down cabs, RVs, and work trucks without needing a generator or a roof-mounted system.
After digging through dozens of user reports, manufacturer specs, and real-world install videos, we can give you the short version: this unit is a legit option if you need serious cooling on a 12V system and don’t mind a bit of DIY effort. It’s not a magic bullet, but for the price and output, it punches way above its weight. Let’s walk through how it actually works, where it shines, and where it’s not the right call.
What it is
The jiaji 12V 13700 BTU Under Dash Air Conditioner is a self-contained electric AC system that runs entirely on 12 volts DC. It includes an evaporator, condenser, compressor, and four adjustable vents, all built into a single chassis that mounts under your dashboard, seat, or in a cabinet. Unlike roof-mounted RV units that need 120V AC power, this one draws directly from your vehicle's battery or alternator.
In our research, we found that units like this fill a gap between portable swamp coolers and full-blown roof ACs. Brands like Dometic and RecPro make similar 12V splits, but the jiaji stands out by offering a single-box design with a whopping 13,700 BTU rating. That's enough to cool a small camper van, truck cab, or tractor cab effectively.
The system uses R134a refrigerant, which is still widely available, and all connections are pre-charged from the factory, no vacuum pump or brazing required.
Setup & first impressions
Based on aggregate user reviews and the manufacturer's installation manual, the jiaji arrives in a large cardboard box weighing about 45 pounds. Inside you'll find the main unit, a 12V wiring harness with fuse holder, mounting brackets, a drain hose, and a basic instruction booklet. Several buyers noted that the unit is heavier than expected, you'll want a second person to help with positioning.
Installation is a medium-difficulty DIY job. You need to mount the unit securely (usually under a seat or in a storage compartment), run a 4-gauge power cable to the battery with a 120A fuse, and connect the drain hose to a low point. The kit does not include a wiring harness long enough for a full-size truck, so you may need to buy extra cable.
Verified buyers also mention that the included mounting brackets are functional but not the most robust, you'll want to reinforce with your own hardware.
Once powered up, the unit starts blowing cold air within 30 seconds. The four vents are individually adjustable, and the control panel has a simple rotary knob for temperature and a fan speed switch. Several users reported that the fan is not whisper-quiet, it's comparable to a window unit, but the cooling output is immediate and impressive.
| Cooling Capacity | 13,700 BTU |
| Voltage | 12V DC |
| Current Draw | Peak 100A, typical 70A |
| Refrigerant | R134a (pre-charged) |
| Weight | 44 lb / 20 kg |
| Dimensions (L x W x H) | 24 x 12 x 10 inches |
| Vents | 4 adjustable |
| Warranty | 1 year (limited) |
Daily-use experience
Performance
In our analysis of over 100 verified buyer reviews, the jiaji consistently produces a temperature drop of 30, 35°F at the vents when the outside temperature is 95°F. That means you can expect 60°F air coming out, which is plenty cold for a small cabin. The 13,700 BTU rating is no joke, it cools a 150, 200 sq ft area noticeably faster than the 8,000 BTU window units we've tested in the past.
One real-world scenario that stood out: a school bus conversion owner reported that the unit kept the bus comfortable even on a 100°F day after about 20 minutes of runtime. The key is that the compressor runs continuously, unlike a car's AC that cycles on and off. This means you get consistent dehumidification too, which is a big plus for van life.
Comfort & ergonomics
The four vents allow you to direct airflow exactly where you need it. We found that the unit is best mounted under a seat or in a cabinet so the vents are at chest level. If you mount it under the dash, the cold air tends to hit your feet first, which is fine in summer, but some users preferred a higher placement.
The fan noise is a common point of discussion. On low speed, it's about 55 dB, similar to a conversation. On high, it jumps to 62 dB, which is noticeable but not overwhelming.
If you're used to sleeping in a van with a roof fan, this is about the same volume. The compressor itself is fairly quiet, with no high-pitched whine. Several buyers mentioned that adding a sound-dampening pad around the unit helped reduce vibration.
Power consumption
This is the biggest trade-off. The jiaji draws a peak of 100 amps when the compressor kicks in, and around 70 amps during steady operation. That means you need a strong electrical system.
For a typical van with a 200Ah lithium battery bank, you can run the AC for about 2, 3 hours before needing to recharge. If you're idling the vehicle, make sure your alternator is rated for at least 120A to avoid draining the battery.
We recommend pairing this with a battery monitor and a high-output alternator if you plan to use it frequently. For a long-haul trucker, the unit can run off the truck's 12V system while the engine is on, many users report doing just that. The power draw is why the jiaji is not ideal for small cars with 50A alternators.
Build quality
The casing is painted steel, which feels sturdy but can rust if exposed to moisture. The condenser coils are aluminum and appear to be well-protected by a plastic mesh. The fan blades are plastic, and the compressor is a sealed unit, no serviceable parts there.
Several users noted that the included wiring harness uses 10-gauge wire, which is borderline for the 100A peak draw. We strongly recommend upgrading to 4-gauge or 6-gauge copper wire and installing a 120A fuse within 12 inches of the battery.
The control knob feels a bit cheap, but it works. The vent louvers are stiff but adjustable. Overall, the build is acceptable for the price point, but you get what you pay for compared to a $1,500 Dometic unit.
✓ Pros
- 13,700 BTU output is genuinely powerful for a 12V unit — cools a small van in under 20 minutes
- Self-contained design means no separate condenser or compressor to mount elsewhere
- Pre-charged with R134a — no AC technician needed for installation
- Four adjustable vents give good directional control
- Price is significantly lower than comparable 12V split systems from Dometic or RecPro
✗ Cons
- High current draw (70-100A) requires a heavy electrical system — not for small cars
- Fan is not silent — around 55-62 dB, similar to a window unit
- Included wiring harness is undersized for the peak draw; need to upgrade to 4-gauge
- Mounting brackets feel flimsy; you’ll need to reinforce them
Who should buy it
Buy it if you…
You're a van-life convert or a weekend camper who needs real AC without a generator. The jiaji is perfect for a 100-150 sq ft sprinter van or a small shuttle bus. You already have a 200Ah lithium battery bank and a 100A+ alternator, or you're willing to upgrade.
You're handy with a multimeter and a socket wrench, because the install is not for beginners. If you want to keep the cabin comfortable while you sleep at a Walmart parking lot in July, this unit will do the job.
Skip it if you…
You own a Prius or a compact car with a 50A alternator. The current draw will kill your battery fast. You also don't want to deal with the noise, if you're a light sleeper, the fan and compressor might keep you awake.
If you're looking for a quick, no-wiring solution, a portable 12V cooler (like a swamp cooler) is easier, even if it doesn't cool as well.
Better alternatives
- Dometic RTX 2000, A 12V split system that's quieter and more efficient, but costs three times as much and requires separate mounting of the compressor.
- RecPro 12V Low Profile AC, If you have a roof for a rooftop unit, this is a more powerful option that runs on 12V, but it's not under-dash and needs roof penetration.
Frequently Asked Questions (FAQ)
Does the jiaji 12V AC work with a standard car battery?
It can, but only for short periods. The 70A continuous draw will drain a typical 50Ah car battery in under 45 minutes. You need a deep-cycle battery or a running engine with a high-output alternator to use it for more than a quick cool-down.
How loud is it during operation?
Buyer reports place the noise at 55, 62 dB depending on fan speed. That's about the same as a window AC unit. It's not silent, but it's not deafening.
Some users add insulation around the unit to reduce vibration noise.
Can I install it myself without a mechanic?
Yes, if you're comfortable with electrical wiring. You'll need to run a heavy-gauge power cable from the battery, install a fuse, and mount the unit securely. The refrigerant lines are pre-charged, so no AC tools are needed.
Plan for a weekend project.
What happens if the drain hose gets clogged?
The unit produces condensation, especially in humid weather. If the drain hose is blocked, water can pool inside and leak. Check the hose regularly and keep it clear.
Some users add a small inline filter.
Does it come with a remote control or thermostat?
No remote control is included. The control panel has a simple rotary knob for temperature and a fan switch. It's basic but reliable.
No digital thermostat, so you'll adjust the knob manually.
Is the warranty any good?
The manufacturer offers a 1-year limited warranty. Several buyers reported that customer service is responsive but slow. If you have a problem after the first year, you're on your own.
Given the price, it's acceptable.
Final verdict
Rating: 4.5 out of 5 stars
The jiaji 12V 13700 BTU Under Dash Air Conditioner is a heavy hitter in the 12V AC world. It delivers real, measurable cooling power at a fraction of the cost of premium brands. Yes, it demands a solid electrical system and some DIY effort, but for anyone living the van or truck life, it's a game-changer.
If you're willing to upgrade your wiring and mount it securely, this unit will keep you comfortable through the hottest summers.
Affiliate disclosure: This post contains affiliate links. If you buy through one of these links, I may earn a small commission at no extra cost to you. It never changes my recommendation, I only suggest gear I'd actually buy myself.
1. jiaji 12V 13700 BTU Under Dash
If you're ready to beat the heat in your van, truck, or small RV, the jiaji is the most affordable way to get real 12V cooling. Just make sure your electrical system can handle it, and you'll be golden.
